High-Performance Semi-Automatic Tube Filling And Sealing Machine In Kenya
Semi Automatic Tube Filling And Sealing Machine Details
High-Performance Semi-Automatic Tube Filling and Sealing Machine in Kenya
Superior Tube Packaging Solutions for Kenya’s Pharma, Cosmetic, and Nutraceutical Industries
Technogen Enterprise proudly presents the Semi-Automatic Tube Filling and Sealing Machine—a compact yet powerful solution tailored for the Kenyan manufacturing industry, spanning from Nairobi’s pharmaceutical hubs to Mombasa’s coastal cosmetic units, and across growing industrial zones in Kisumu, Eldoret, Thika, Ruiru, and Nakuru.
This versatile machine is designed for precision filling and secure sealing of laminated and aluminium tubes, making it ideal for creams, ointments, pastes, gels, adhesives, and semi-solid products. Engineered to handle both viscous and semi-viscous materials, it helps Kenyan businesses streamline production while maintaining the highest quality and hygiene standards.
Designed for Flexibility and Accuracy
At Technogen Enterprise, we understand the dynamic needs of Kenya’s industrial landscape. Whether you’re a cosmetic producer in Kisumu, a pharmaceutical plant in Ruiru, or an Ayurvedic manufacturer in Nairobi, our TGAU-30S Semi-Automatic Tube Filling and Sealing Machine brings unmatched versatility and cost-efficiency to your operations.
This equipment can easily switch between plastic (Lami) tubes and aluminium tubes, offering seamless performance across applications.
Machine Operation: A Step-by-Step Breakdown
Tube Loading and Detection
The operator manually feeds empty tubes into durable nylon holders. Thanks to the No Tube–No Fill sensor system, the machine automatically detects tube presence before initiating the fill cycle, eliminating product wastage.
Accurate Filling System
Upon tube detection, the stainless steel pump assembly advances and fills the tube with the pre-set volume of product. The contact parts are made from AISI 316L stainless steel, ensuring top-tier hygiene and corrosion resistance—ideal for GMP-certified Kenyan facilities.
Sealing and Coding
After filling, the tube is automatically indexed to the sealing station. Here, aluminium tubes are folded, while laminated tubes are sealed using heat (if optionally configured). A built-in coding system embosses the batch details on the sealed end, helping manufacturers meet Kenyan regulatory traceability requirements.
Tube Ejection
Finally, the ejection rod lifts the sealed tube from its holder and transfers it to the receiving hopper using a tipper. This automatic ejection process keeps the cycle flowing and reduces manual handling.
Key Features and Benefits
✅ CGMP-Compliant Design
The machine complies with Current Good Manufacturing Practices, aligning with the regulatory expectations of Kenyan authorities like the Pharmacy and Poisons Board (PPB) and other East African standards.
✅ Hygienic Contact Parts
All contact parts are made of AISI 316L stainless steel, ensuring cleanliness, durability, and compliance—especially crucial in pharmaceutical and personal care applications.
✅ Precision and Consistency
The ±2% filling accuracy helps eliminate overfilling or underfilling—critical for cost control and product uniformity, whether you're packaging toothpaste in Nairobi or gels in Mombasa.
✅ Easy Speed Control
Equipped with a CE-certified Variable Frequency Drive (VFD), users can control the operating speed based on the material type and operator capability.
✅ Durable Tube Holders
The machine’s nylon-based tube holders provide long operational life and consistent holding, even during long production runs.
✅ 23-Litre Jacketed Hopper
The large capacity hopper ensures uninterrupted filling, especially beneficial for high-volume manufacturing units in Thika or Eldoret.
✅ Compact and Robust
With a stainless steel matt finish, the machine is aesthetically pleasing and corrosion-resistant. Its compact footprint makes it suitable for urban pharmaceutical labs and manufacturing plants.
✅ Built-In Batch Coding
A mechanical coding unit embosses manufacturing details on each tube’s sealed end, ensuring compliance and ease of traceability.
✅ Inbuilt Production Counter
Real-time production monitoring is made easy with the integrated digital counter, allowing factory managers to track progress efficiently.
✅ User-Centric Panel
A bottom-mounted pendant control panel offers intuitive controls for start, stop, speed adjustment, and emergency handling.
Technical Specifications: TGAU-30S Model
| Feature | Specification |
|---|---|
| Machine Name | Semi-Automatic Tube Filling and Sealing Machine |
| Model | TGAU-30S |
| Brand | Technogen Enterprise |
| Direction of Operation | Left to Right |
| Applications | Creams, gels, pastes, ointments, adhesives |
| Suitable Tube Types | Lami Tubes & Aluminium Tubes |
| Filling Volume Range | 10 to 150 grams |
| Tube Diameter Range | 12 mm to 32 mm |
| Tube Height Range | 55 mm to 190 mm |
| Production Speed | 30–40 tubes/min (depends on material & operator) |
| Filling Accuracy | ±2% |
| Number of Filling Heads | 1 |
| Sealing Head | 1 |
| Speed Control | VFD – Variable Frequency Drive |
| Power Consumption | 2.5 kW |
| Electrical Requirements | 440V, 3 Phase, 4-Wire, 50Hz |
| Control Panel | Bottom pendant type, machine-mounted |
| Production Counter | Integrated digital display |
| Hopper Material | AISI 316L Stainless Steel (23-litre capacity) |
| Machine Dimensions (mm) | 1400 (L) × 1150 (W) × 1750 (H) |
| Conveyor Height | Adjustable from 800 mm to 850 mm |
| Net Weight | 275 KG |
| Gross Weight | 500 KG |
| Country of Origin | Made in India |
Ideal Industries in Kenya
The TGAU-30S machine is perfect for a wide range of sectors across Kenya’s growing economy:
Pharmaceutical Companies – for filling medicated creams, gels, and ointments
Cosmetic Manufacturers – for packaging facial creams, herbal pastes, and beauty gels
Ayurvedic & Herbal Units – ideal for natural product-based companies in Nairobi or Nakuru
Toothpaste and Dental Product Producers – suitable for viscous dental care formulations
Nutraceutical Companies – for sports creams, wellness gels, etc.
Whether you are part of a large-scale enterprise in Nairobi Industrial Area, or a growing SME in Ruiru EPZ, this machine meets your packaging needs with precision and efficiency.
Why Technogen Enterprise?
Technogen Enterprise is recognized globally for delivering cutting-edge machinery with Indian innovation and global standards. We offer:
Customizable Solutions for your specific tube size or application
After-sales support across Kenya, including installation, training, and maintenance
Quick delivery with coordination through Mombasa Port or Nairobi air freight
Affordable pricing with no compromise on international build quality
We have successfully supported installations in pharma parks, manufacturing clusters, and laboratory environments throughout Kenya and other African markets.
Request a Quote or Consultation
Ready to elevate your packaging operations with Kenya’s most trusted semi-automatic tube filling and sealing solution?
Technogen Enterprise is ready to serve you across Nairobi, Mombasa, Kisumu, Eldoret, Nakuru, Ruiru, and beyond.
Final Thoughts
Investing in the TGAU-30S Semi-Automatic Tube Filling and Sealing Machine is not just about speed—it’s about quality, compliance, hygiene, and future readiness. With Kenya’s pharmaceutical and personal care sectors expanding rapidly, the time to upgrade your packaging capabilities is now.
Choose Technogen. Choose reliability. Choose performance.
